SilverCrest STWT 720 A1
English - 15
 Attach the battery compartment cover using the screws [E].
8.2 Assembly
The doorbell can be mounted on the wall. To mount the doorbell, proceed as follows:
CAUTION! Ensure that there are no cables running behind the wall where you will be
mounting the access point! The manufacturer assumes no liability for improper or incorrect
assembly or any damages resulting from drilling.
 Choose a suitable place to mount the device on the wall. When doing so, ensure that the lens [2]
covers the required viewing range.
You can also start operating the doorbell and controlling the viewing range before
assembling the wall mount [B].
 Hold the wall mount [B] in the required position and use a pencil to draw four drill holes on the wall.
 Drill the marked holes using a suitable 6 mm drill.
 Assemble the wall mount [B] by inserting the plugs provided [F] and screwing in the screws [G].
 Insert the outdoor unit [A] into the previously installed wall mount [B]. Use the screwdriver [D]
provided to twist the locking screw [H] through the wall mount [B] and into the thread [6] of the
outdoor unit [A].
