SilverCrest SWV 733 A1
English - 253
Overview
These operating instructions have a fold-out cover. The dual-band wifi range extender is illustrated with
numbers on the inside cover. The numbers indicate the following:
1 Field strength indicator
2 WAN/LAN LED
3 LAN LED
4 Power/WPS LED
5 Reset button
6 WAN/LAN socket (network socket, RJ-45)
7 LAN socket (network socket, RJ-45)
8 Mode selector
9 WPS button
10 Main switch
