ENGLISH
7. SOLUTIONS TO MOST FREQUENT ANOMALIES
ANOMALY POSSIBLE CAUSE SOLUTION
Loose or damaged belts Tighten belts or change
Cutting/bending power insufficient
Power drop in motor Let the technical service check the
motor
The bending plate turns but only stops
after touching the course end.
Defect end of course
Check the stopping course end and
confirm its continuity. (1 open, 0
closed). Substitute it in case of defect
Check there is tension in the
Faulty tension the machine, the pilot
lamp indicating the state of energy
does not ignite.
Defect electrical connection.
Check switch board at work place
workplace. Check the high and low
tension fuses of the machine switch
board. Check the connection of the
cables.
The LED is on but the machine does
not work.
The machine is not well connected
The machine is connected by one
phase. Check the high tension fuses
of the machine switch board and that
of the work place. Check the
connection of the cables in the switch
board, base and the plug.
230V or 400V connection. It is regular
but the machine would not run.
Unstable tension
Check emission stream exit. If the
voltage is inferior to 230V or 400V the
machine will not run. It is
recommended then to used a tension
stabiliser.
During regression and after bending,
the bending plate does not stop at the
starting point.
End of course
Check the end of course and its
continuity (1 open 0 closed).
8. TECHNICAL CHARACTERISTICS
MODEL MOTOR
POWER
MOTOR
TENSION
NET WEIGHT DIMENSIONS LxAxH
mm
ROTATION/MIN.
STAR-16 2,2Kw 230v 149 Kg. 1136x738x1095 19
STAR-16 1,5Kw 230v / 400v 140 Kg. 1136x738x1095 19
9. BENDING CAPACITY
Resistance of the
steel bars
Nº of bars Ø6
o 1/4"
Nº of bars Ø8
o 5/16"
Nº of bars Ø10
o 3/8"
Nº of bars Ø12
o 1/2"
Nº of bars Ø16
o 5/8"
R-480 N/mm² 7 6 5 3 1
R-650 N/mm² 7 6 5 2 1
Doblado con
mandril de Ø
18 24 36 36 48
9
