scorpION3 5200969 Rev 4 38
5.1 Specifications
scorpION3 Bar
Input Votage 24 VDC, 200 mA (max per bar) provided through the RJ-11 modular jack
Discharge <10 sec (typ), 24” with 90 fpm unidirectional airflow
1
Balance <30V (typ), 24” with 90 fpm unidirectional airflow
Timing
0.125-6 sec, adjustable in 0.025 sec increments; steady state operation is
also available
Pulse Overlap 0-100%, adjustable in 0.25% increments
Connectors
6-pin RJ-11 modular jacks provide both power and communications
interconnections
LED Indicators
2 bicolor LEDs provide information on pos/neg high voltage power supplies
and feedback condition; green NORMAL; red FAULT
Address Control Each bar can be set to one of 10 unique addresses
Mode Control
Independent or slave; independent bars can be set to steady state or a
pulse rate independent of the system; slave bars will follow the pulse timing
of the master bar
Communications RS-485
Fault Interface
3.5 mm (1/8”) phone jack, opto-isolated transistor that can be set to
normally off or normally on, this transistor (NEC PS2502-1) is toggled
during a fault condition. Phone jack connections: Tip - positive (collector),
Sleeve - negative (emitter), Fault Interface Maximum Ratings: Vceo
(collector emitter voltage) 40 VDC max; Veco (emitter to collector voltage)
6 VDC max; IC (collector current) 50 mA max
Emitters Points Replaceable Ultra-clean Silicon or Tungsten
Cleanliness
ISO 14644-1 Class 1 (Ultra-clean Silicon), ISO 14644-1 Class 4 (Fed. Std.
209e Class 10) (Tungsten)
Operating Env. Temperature 15-35°C (59-95°F) recommended; relative humidity 20-65%
Ozone <0.020 ppm
EMI Below background level
Mounting
Stainless steel brackets, with universal adjustable mounting centers.
Clamping thumbscrew Integrated #8-32 mounting nut
Enclosure Reinforced Polycarbonate
Dimensions
457 mm (18”); 610 mm (24”); 914 mm (36”); 1118 mm (44”); 1626 mm (64”);
1880 mm (74”); 2134 mm (84”)
