scorpION3 5200969 Rev 4 40
1. Tested in accordance with ANSI/ESD STM3.1-2006.
CI Module
Input Power
24 VDC, 100 mA from bar system chain (RJ-11 modular connectors) or
User Interface terminal block
Bar Connection RJ-11 modular jack/modular wire (power & communication)
Network Interface Ethernet (RJ-45 modular connector)
LED Indicators Green POWER; red FAULT
Dimensions 84 x 211 x 34 mm (3.30 x 8.30 x 1.35 in.)
Enclosure Stainless Steel
Software Windows 2000, Windows XP, Windows 7
