SIM7022-EVB User Guide V1.00
www.simcom.com
19
/
33
Feature 12: LED status indicator light (LED101、LED102、LED103)
Table 8: Status indicator light description
LEDs number
LEDs colour
Description
LED101
Blue
Module network status indicator light
LED102
Red
VBAT power supply indicator light
LED103
Blue
Module power-on status indicator light
2.5 Switches and Buttons
There are two switches (SW101, SW1) and two buttons (SW102, SW103) on SIM7022 EVB.
