14
■ Technical Parameters
Model
ECOMAXI VB 80
ECOMAXI VB 120
Operational mode
Heat pump, Automatic and Boost mode
Power supply
220-240V~ 50Hz
Max. power input (under boost mode)
2300W
2300W
Max. current input (under boost mode)
10.2A
10.2A
Heat pump
Max. power input
800W
800W
Heating up time(7/6
℃
)
2:25 (h:min)
4:05 (h:min)
Heating up time(14/13
℃
)
1:56 (h:min)
3:25 (h:min)
Refrigerant
R134a/540g
R134a/540g
Declared load profile
M
M
COP
DHW
(7/6
℃
)
2.45
2.45
COP
DHW
(14/13
℃
)
2.77
2.89
Mixed water at 40
℃
79L
135L
Energy efficiency(7/6
℃
)
104.7%
102.1%
Energy efficiency(14/13
℃
)
117.6%
121.0%
Energy efficiency class
A
+
A+
Max. outlet water temp.
65
℃
(default 50
℃
)
Operating temp. range
-7
℃～
43
℃
Electric
heating
Rated power input
1500W
Max. outlet water temp.
75
℃
Max. operating pressure for refrigerant
circuit (discharge side/suction side)
2.4MPa/0.6MPa
Storage
tank
Rated capacity
80L
120L
Max. operating Pressure
0.8MPa
Water inlet/outlet
DN15
Anti-electric shock class
Class Ι
Sound power level
58dB (A)
60dB (A)
Net weight(kg)
57
67
Gross weight(kg)
71
85
Dimensions(mm)
560*575*1230
560*575*1550
Note (1): The test conditions for rated parameters are dry-bulb temperature of 7
℃/14℃
, wet-bulb
temperature of 6℃/13℃, inlet water temperature of 10℃, outlet water temperature of 50℃, according
to EN 16147:2017, (EU) NO 814-2013.
Note (2): Sound power level tested with air duct, according to EN 12102-1-2017, ISO 3744:2010.
ATTENTION
The parameters in the above table are only for reference. When the contents of this table differ
from those of the nameplate on the appliance, please refer to the nameplate.
