WARNING: If the information in this manual
is not followed exactly, a fire of explosion may
result causing property damage, personal
injury or loss of life.
• Do not store or use gasoline or other flam-
mable liquids or gases in the vicinity of this or
any other appliance.
• WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliances.
• Do not touch any electrical switches, do
not use any phone in your building.
• Immediately call your gas supplier from a
neighbour’s phone. Follow the gas sup-
plier’s instructions.
• If you cannot reach the gas supplier, call
the fire department.
• Installations and service must be performed
by a qualified installer, service agency or the
gas supplier.
Warning: Do not use this boiler if any part has been
under water. Immediately call a qualified service tech-
nician to inspect the boiler and to replace any part of
the control system and any gas control which has
been under water.
Warning: Should overheating occur, or the gas supply
fail to shut off, shut off the gas supply external to the
appliance. Do not switch off the electrical supply to
the pump.
Installation Instruction
and Care Guide
Planet Dewy 30/50 BF of Gas-Fired Wall Hung Hot Water Boilers
TABLE OF CONTENTS
1 DESCRIPTION OF THE BOILER 4
1.1 INTRODUCTION 4
1.2 DIMENSIONS 4
1.3 TECHNICAL FEATURES 5
1.4 FUNCTIONAL DIAGRAM 6
1.5 MAIN COMPONENTS 6
2 INSTALLATION 7
2.1 VENTILATION OF BOILER ROOM 7
2.2 BOILER SUPPORT BRACKET 7
2.3 CONNECTING UP SYSTEM 7
2.5 SYSTEM FILLING 8
2.6 FLUES/CHIMNEYS 8
2.8 POSITIONING OF OUTLET TERMINALS 11
2.9 ELECTRICAL CONNECTION 26
2.10 LOGICA REMOTE CONTROL 28
2.11 EXTERNAL TEMPERATURE SENSOR 30
3 CHARACTERISTICS 31
3.1 ELECTRONIC BOARD 31
3.2 TEMPERATURE SENSOR AND
WATER PRESSURE TRANSDUCER 32
3.3 ELECTRONIC IGNITION 32
3.4 FLOW SWITCH SAFETY VALVE 33
3.5 SMOKE STAT 33
3.6 SYSTEM AVAILABLE HEAD 33
3.7 MAINS ELECTRICITY CONNECTION 33
4 USE AND MAINTENANCE 35
4.1 GAS CONVERSION 35
4.2 GAS VALVE 35
4.3 CLEANING AND MAINTENANCE 36
