Sime SOLIDA Series - 2.2 Installation; 2.2.1 Boiler Adaptation for Pellet Operation

10
INSTALLATION2.2
BOILER ADAPTATION FOR OPERATION WITH PELLETS AND SPECIAL KIT2.2.1
Remove the cast iron cover plate from the lower door. Open the door and remove the latch and screws securing the grill. remove the grill.A)
Remove the blind plateFig. 13 Remove the grilleFig. 14
Place the cast iron deflector with the rear side supports.B)
1Fig. 15
st
deflector 1Fig. 16
st
deflector
Place the cast iron deflector with the front side supports.C)
2Fig. 17
nd
deflector 2Fig. 18
nd
deflector
