14
GLASS MOUNTING INSTRUCTIONS
Figure 1 Figure 2
Place your product on a at, level ground. Mount your glass by plac-
ing it on the mounting rack below by placing one side, then placing on
the other side and x it as shown in Figure 2.
Figure 3 Figure 4
. Place the glass stoppers, tabs facing back, on the lower and upper
rack and press them to ensure that they are xed on the racks, as
shown in Figure 3. Apply the same procedure on the other side, place
the 4 stoppers on the lower and upper racks. Pull the glass to the right
side.
. Mount your glass by placing it on the mounting rack above by plac-
ing one side, then placing on the other side and pull the upper glass to
the right as shown in Figure 4.
