specifications
Signal flow diagram
Output Power 50W / 8 ohm Output to speakers
500mW / 32 ohm Output to headphones
Frequency Response 20 -20KHz Actual response is tailored for accurate acoustic
reproduction of individual sounds
Total Harmonic Distortion 1.00% At full output
0.05% Nominal
Hum and Noise -60 dBV All controls down
-55 dBV All controls at 12 o’clock
Input Impedance 10K ohms All Inputs
Input Levels -10 dBV DRUM INPUTS to achieve full output
-10 dBV AUX to achieve full output
0 dBV Line In to achieve full output
Tone controls (EQ Centers) 60 Hz, 800 Hz, 10 kHz 3 band, ±12 dBV
AC Power Requirements 80W At full output
7W At idle
Dimensions English 15.5” Deep, 15.5” Wide,
16” Tall (including feet)
Dimensions Metric 39.37cm Deep, 39.37cm Wide,
40.64cm Tall (including feet)
Weight - Lbs/Metric 33 lbs/ 15 Kg
Speakers 1 x 10” (250mm) Woofer,
1 x 2” (51mm) Tweeter
Model DA50 Powered Drum Monitor
(All measurements made at 1 kHz,
EQ controls flat and volumes Max.)
DRUM Amplifier
