Simmons SD300KIT User Manual

7
www.simmonsdrums.ne t
connections
CAUTION!
To prevent electric shock and damage to the device, make sure the power is switched
OFF on the sound module and all related devices before making any connection.
*See Appendix for Pad, Triggers, Name and MIDI chart.
To Hi-Hat
To Ride
To Tom 3
To Tom 1
To Tom 2
To Crash
To Hi-Hat
Control
To Kick
Cymbal Pads
Drum Pads
Sound
Module
To Snare
From Sound
Module to 7 Pads
Connecting the Pads
