8
COMPLIANCE WITH Z-WAVE PROTOCOL
This product can be included and managed in a Z-Wave network, working with Z-Wave certified devices and applications from other manufacturers. All
non-battery devices act as repeaters within the Z-Wave network in order to increase the reliability of the network. This product and meets the Z-Wave
Plus safety standards with S2 safety.
CC BASIC MAPPING OF VALUES
SPECIFICATION OF THE DEVICE Z-WAVE
Basic Set
Device Type
Generic Device Type
Specific Device Type
Role Type
Basic Report
0x00 -> The device turns into mode OFF
Thermostat - HVAC
0xFF -> Set the heat mode to AUTO
GENERIC_TYPE_THERMOSTAT
0x00 -> Indicates that the device is in mode OFF
SPECIFIC_TYPE_THERMOSTAT_GENERAL_V2
0xFF -> Indicates that the device is in a mode other than OFF
ROLE_TYPE_SLAVE_ALWAYS_ON
CC THERMOSTAT MODE ADMITTED
THERMOSTAT_MODE_OFF
THERMOSTAT_MODE_HEAT
THERMOSTAT_MODE_AUTO
THERMOSTAT_MODE_
AWAY_HEATING
The device is stopped and does not work
The device is active working with the
Setpoint set for heat
The device is active working according
to schedule parameters
The device is active working in low
power mode with a reduced SetPoint
temperature
COMMAND CLASSES SUPPORTED
CC_ASSOCIATION_GRP_INFO_V3
IU: Included in an unsecured way
UonS: Unsecured request when included securely
SonS: Secure request when included securely
IU, SonS
IU, UonS
IU, SonS
IU, SonS
IU, SonS
IU, SonS
IU, SonS
IU, SonS
IU, SonS
IU, SonS
IU, SonS
IU, SonS
IU, SonS
IU, UonS
IU, SonS
IU, SonS
IU, SonS
IU, SonS
IU, UonS
CC_DEVICE_RESET_LOCALLY_V1
CC_THERMOSTAT_MODE_V2
CC_TIME_V1
CC_ASSOCIATION_V2
CC_SECURITY_S2
CC_FIRMWARE_UPDATE_MD_4
CC_THERMOSTAT_OPERATING_STATE_V1
CC_TRANSPORT_SERVICE_V2
CC_BASIC_V1
CC_SENSOR_MULTILEVEL_V5
CC_MANUFACTURER_SPECIFIC_V2
CC_THERMOSTAT_SETPOINT_V3
CC_VERSION_V2
CC_CONFIGURATION_V2
CC_SUPERVISION
CC_POWERLEVEL_V1
CC_TIME_PARAMETERSV1
CC_ZWAVEPLUS_INFO_V2
COMMAND_CLASS_SENSOR_MULTILEVEL SENSOR_MULTILEVEL_REPORT. Reported temperature and humidity when the
conditions established by the user are met through the configurations 30, 31, 32, 33.
COMMAND_CLASS_THERMOSTAT_MODE.THERMOSTAT_MODE_REPORT
Transmitted when the work mode changes due to a local action or through the Network controller.
COMMAND_CLASS_THERMOSTAT_OPERATING_STATE.THERMOSTAT_OPERATING_STATE_REPORT
Transmitted when the device changes the status of the climate system management.
COMMAND_CLASS_THERMOSTAT_SETPOINT.THERMOSTAT_SETPOINT_REPORT
Transmitted when the setpoint temperature changes either by local action, by the controller of the Network or by time conditions.
COMMAND_CLASS_DEVICE_RESET_LOCALLY_NOTIFICATION
It is sent to the associated nodes when the device is removed from the Z-Wave network.
ASSOCIATION GROUPS
Group
Slides number
Automatic Reports
Group 1 (Lifeline) -> Name “lifeline”
1
