6. Appendix A. Specifications
HP200PT64 Specifications
Protocols
&
Performance
Frequency band
2
～
30
M
H
z
.
PHY rate 200Mbps maximum.
Throughput TCP stream: up to 65~70Mbps. UDP stream: up to 85-90Mbps
Mo
du
l
a
tio
n
OFDM support 1024/256/64/16/8 QAM, QPSK, BPSK, ROBO modulation schemes.
Encryption method AES 128bit encryption with key management.
HomePlug® AV MAC:
TDMA and priority-based CSMA/CA channel access schemes maximize efficiency and
throughput.
Power
Requirement
Power rating
100 -240VAC , 50Hz/60Hz ; Tolerance: 50Hz +/- 3% 60Hz +/- 3.5%.
Power consumption
Full operation: 2.9W @ 100VAC , 3.8W @ 240VAC.
Idle mode: 2.2W @ 100VAC , 3.2W @ 240VAC (No Ethernet Activity).
Standby mode: 0.9W@ 100VAC, 1.8W @ 240VAC (Ethernet cable removed).
AC Power plug Maximum current 16A @ 100-240VAC
AC Filter attenuation -25dB~ -40dB @ 2-30Mhz
AC Power Outlet Maximum current 16A @100-240VAC
Physical
interface
LAN Interface One 10Base-T/100Base-TX port, Auto MDI/MDI-X detection
LAN Data transfer rate
10Mbps /100Mbps
Buttons
NMK— Encryption / Synchronization.
RST — Reset to factory default setting. (miss-touch protection reset hole design)
3 LED indicators
PWR— Power status.
LINK— Powerline Link status & throughput range indication.
ETH — Ethernet Activity status.
Flash
SDRAM
2MB Flash
16MB SDRAM
 Connectivity: Maximum 64 PLC AV devices per HomePlug AV logical Network.
 Max MAC addresses: 4096 NIC’s source-aware bridging capability.

TX Buffering: 340 ms of the Max Powerline devices disturbance that can be
withstood without packet loss.
Qos (Quality of Service)
 Contention-free access, four-level priority based contention access and multi
segment bursting.
 Tos, CoS and IP Port Number Packet Classifiers.
 Supports IGMP managed multicast sessions.
IGMP
 Enhanced IPv4/IGMPv1-3 snooping for multicast address and source specific
query.
 Enhanced IPv6 and MLDv1-2 snooping for multicast address and source specific
query.
Firmware
HomePlug AV Firmware version: v4.1 ; upgradable
System Requirements Microsoft Windows 98,SE,XP, 2000, Vista, Windows 7 for Powerline user utility
Software Utility
Power Packet Powerline user utility:
 HomePlug device & MAC address indication.
 DAK & NMK configuration for create a private powerline network.
 Link information indication.
 Firmware upgrade function.
Standards & Regulations
 802.3 , 802.3u , HomePlug 1.1 co-existence.
 Low Voltage Directive 2006/95/EEC.
 EMC Directive 2004/108/EEC.
 CE Class B.
 RoHs Compliant.
Environment conditions
 Operating temperature: 0℃ to 40℃.
 Storage temperature: -25℃ to 70℃.
Dimensions
125mm (H) x66mm (W) x 43mm (D).
Packaging
1x White Box include 2x PLC adapters, 1x Manual CD, 2x 1.8m RJ-45 Cat.5 cable,
1x Printed Quick User Guide.
