Simplex Flex 4100U - Page 9

9
I/O Wiring I/O Wiring I/O Wiring
Block A
Flex Amp
Block C
Expansion
Power
Supply
(XPS)
Space
Not
Available
Block B Block D
Slots 5 & 6 Slots 7 & 8
Flex Amp
Figure 5. Mounting Placement (Two Flex Amplifiers)
Continued on next page
Installing the Amplifier onto the PDI, Continued
