Simplex P140 Instruction Sheet

2
ISPECIFICATIONS: Use this instruction sheet for the following hand pump
models.
Hand Pump Specifications
Model Type Maximum Pressure Oil Volume per Stroke Usable Oil Capacity
(Speed) Rating psi [bar] in
3
[cm
3
] in
3
[cm
3
]
P20 1 2,850 [200] .16 [2.62] 20 [328]
P41 1 10,000 [700] .16 [2.62] 45 [738]
P70 1 10,000 [700] .16 [2.62] 70 [1147]
P71 1 10,000 [700] .19 [3.1] 70 [1147]
Stage 1 Stage 2 Stage 1 Stage 2
P140 2 400 [28] 10,000 [700] 2.8 [45.9] .24 [3.9] 140 [2295]
P140D 2 400 [28] 10,000 [700] 2.8 [45.9] .24 [3.9] 140 [2295]
P22 2 200 [14] 10,000 [700] .23 [3.8] .06 [1] 20 [328]
P30 2 200 [14] 3,000 [207] .91 [14.9] .19 [3.1] 30 [492]
P32 2 200 [14] 10,000 [700] .82 [13.4] .16 [2.6] 30 [492]
P42 2 200 [14] 10,000 [700] .82 [13.4] .16 [2.6] 45 [738]
P82 2 200 [14] 10,000 [700] .82 [13.4] .16 [2.6] 145 [2377]
P72 2 200 [14] 10,000 [700] .91 [14.9] .19 [3.1] 70 [1147]
P461 2 400 [28] 10,000 [700] 7.7 [126.2] .3 [4.9] 460 [7539]
P461D 2 400 [28] 10,000 [700] 7.7 [126.2] .3 [4.9] 460 [7539]
CAUTION
Always use the handle to carry the pump. Carrying the
pump by the hose may damage the hose and/or the pump.
WARNING
Always check product specifications regarding pressure
ratings, and capacities. The system operating pressure
must not exceed the pressure rating of the lowest rated
component in the system.
WARNING
NEVER set the relief valve to a higher pressure than the
maximum rated pressure of the pump. Higher settings may
result in equipment damage and/or personal injury.
INSTALLATION
Connecting the Pump
1. Thread hose into pump outlet. Use 1/2 wraps of Teflon tape (or suitable
thread sealant) on hose fitting, leaving the first complete thread free of tape
A Division Of Templeton, Kenly & Co., Inc.
Instruction Sheet
Hydraulic Hand Pumps

Simplex P140 Specifications
