579-1190
Rev. D
Appliance specifications
Environmental specifications:
Rated DC Control/Strobe
Voltage Range
SPECIAL APPLICATION 23-30 VDC
Temperature Range
32 °F to 120° F (0 °C to 49 °C)
Humidity Range
10 % to 93 %, non-condensing at
104 °F (40 °C)
Connections
Terminal for 18 AWG to 12 AWG
(0.82 mm
2
to 3.31 mm
2
)
CAUTION:
• The appliances are available in Red and White. Do not
paint or otherwise alter the factory finishes in any way.
Maximum RMS operating current
Candela
selection†
Appliance
type
UL1971/ULCS526
Clear/White
UL1638/ULCS526
Colored Lens
23V* 23V*
15 cd S/V 47 mA 54 mA
30 cd S/V 57 mA 78 mA
75 cd S/V 100 mA 128 mA
110 cd S/V 132 mA 184 mA
135 cd S/V 160 mA 211 mA
185 cd S/V 208 mA -NA-
Speaker Only SO 9 mA -NA-
* For connection to IIDNAC SLCs
† The use of optional colored lenses can affect the device’s candela
output. To find the candela output for each color consult the TrueAlert ES
WM S/V Colored Lens
document (579-1192).
Percent of rated light output at any candela setting
(room temperature)
Vertical dispersion Horizontal dispersion
Y-Plane
Angle
UL Req
Output
Typical
Output
X-Plane
Angle
UL Req
Output
Typical
Output
0 100 % 194 % 0 100 % 194 %
5 90 % 192 % ±5 90 % 203 %
10 90 % 132 % ±10 90 % 168 %
15 90 % 129 % ±15 90 % 155 %
20 90 % 145 % ±20 90 % 166 %
25 90 % 150 % ±25 90 % 169 %
30 90 % 112 % ±30 75 % 164 %
35 65 % 124 % ±35 75 % 151 %
40 46 % 114 % ±40 75 % 145 %
45 34 % 90 % ±45 75 % 121 %
50 27 % 91 % ±50 55 % 97 %
55 22 % 78 % ±55 45 % 83 %
60 18 % 72 % ±60 40 % 79 %
65 16 % 68 % ±65 35 % 70 %
70 15 % 75 % ±70 35 % 59 %
75 13 % 74 % ±75 30 % 50 %
80 12 % 68 % ±80 30 % 51 %
85 12 % 63 % ±85 25 % 45 %
90 12 % 45 % ±90 25 % 41 %
Wall speaker specifications
Input Voltage
25 VRMS or 70.7 VRMS - Speakers are for connection to compatible fire alarm audio
circuits.
Power Taps via Jumper J1 1/4 W, 1/2 W, 1 W and 2 W
Frequency
Response
Fire Alarm 400 Hz to 4000 Hz [SV/SO]; 200 Hz to 10000 Hz [HFV/HF]
General Signaling 125 Hz to 12 kHz
TrueAlert Addressable Wall Mount S/V and SO Units - speaker jumper setting (25 V or 70 V audio)
Voltage
Jumper J1
to Tap
Tap setting
in Watts
UL1480 at 10 ft ULC-S541 at 3 m
HiSPL (SV/SO)
Models
HiFi (HFV/HF)
Models
HiSPL (SV/SO)
Models
HiFi (HFV/HF)
Models
Speaker
Only
A/E 1/4 79 76 80 76
B/F 1/2 83 80 84 79
C/G 1 87 83 88* 82
D/H 2 90 86 91* 85*
Speaker
Visible
A/E 1/4 79 76 81 78
B/F 1/2 83 80 84 81
C/G 1 86 82 88* 84
D/H 2 89 86 90* 87*
NOTES:
• Reverberant
dBA measurements are a minimum UL rating based on sound level measurements made in UL’s reverberant test chamber.
• Anechoic dBA measurements are a minimum ULC rating based on sound pressure level measurements made in ULC’s anechoic test chamber.
• The sound pressure level decreases by 3 dB at an angular displacement of 75° from the line perpendicular to the speaker’s center. The SPL
decreases by 6 dB at an angle of 85° from that line.
* Only marked settings may be used for ULC fire alarm applications.
