DIMENSIONS
14HP Rider w/ 38” Deck
Height 43.5 in (110.5 cm)
Rider Width 41 in (104 cm)
Length 61.5 in (156 cm)
Wheel Base 43.75 in (111 cm)
Net Weight 581 lbs. (264 kg)
16HP Rider w/ 44” Deck
Height 43.5 in (110.5 cm)
Rider Width 41 in (104 cm)
Length 61.5 in (156 cm)
Wheel Base 43.75 in (111 cm)
Net Weight 620 lbs. (281 kg)
18HP Rider w/ 50” Deck
Height 43.5 in (110.5 cm)
Rider Width 41 in (104 cm)
Length 61.5 in (156 cm)
Wheel Base 43.75 in (111 cm)
Net Weight 686 lbs. (311 kg)
MOWER:
50” Mower Deck
Thickness 12 Ga.
Effective Cut Width 50 in (127 cm)
Overall Width With Deflector — 62 in (157.5 cm)
Weight 135 lbs. (61.4 kg)
Cutting Height Variable Between 1-3.6 in. (2.5-9.1 cm)
Cutting Width 50” in (127 cm)
Blade Arrangement Three Staggered Blades
Mower Drive V-Belt from Rider PTO Electric Clutch
Spindle Bearings Sealed Ball Bearings - Lube Fitting Provided
44” Mower Deck
Thickness 12 Ga.
Effective Cut Width 44 in Mower - 44 in (111.8 cm)
Overall Width With Deflector — 56 in (142.2 cm)
With Turbo — 58in (147 cm)
Weight 107 lbs. (49 kg)
Cutting Height Variable Between 1.25—4 in. (3.2—10.2 cm)
Cutting Width 44” in (112 cm)
Blade Arrangement Three Staggered Blades
Mower Drive V-Belt from Rider PTO Electric Clutch
Spindle Bearings Sealed Ball Bearings - Lube Fitting Provided
38” Mower
Thickness 12 Ga.
Effective Cut Width 38 in Mower - 38 in (97 cm)
Overall Width With Deflector — 49.5 in (126 cm)
With Turbo — 51.5 in (131 cm)
Weight 81 lbs. (36.7 kg)
Cutting Height Variable Between 1.25—4 in. (3.2—10.2 cm)
Cutting Width 38” in (97 cm)
Blade Arrangement Two Staggered Blades
Mower Drive Clutch V-Belt from Rider Engine PTO Electric
Spindle Bearings Sealed Ball Bearings - Lube Fitting Provided
