C-12
A
B
E
D
C
F
Mower deck installation
The muffler and surrounding areas may be hot.
1. Park tractor on a hard, level surface such as a concrete
floor. Move the PTO switch (B) and ignition switch (E)
to the off position, remove the key, depress the brake
pedal (D), and apply parking brake (C).
2. If not already done, orient the discharge tube (G) as shown
and insert it up through the middle of the tractor.
3. Place cutting height adjust (F) in the lowest cutting position.
Place the mower deck lift lever (A) in the lowered position
also. Slide mower deck under the right side of tractor so that
mower deck hitch is aligned with front tractor hitch.
(procedure continues)
G
