C-13

Mower deck installation

(continued)

4. Turn wheels straight ahead. Pull the spring-loaded lever (M)

while lifting up on the mower deck hitch. Install mower

deck hitch onto tractor hitch brackets (L).

5. Connect the mower deck lift arm (H) to the tractor lift

arm (G) using the flat washer and safety clip (I).

6. Move idler arm (J) to relieve belt tension. Install the belt

onto the PTO pulley (K).

7. Secure the discharge tube to the mower deck.
