29
TP 400-7090-01-CT-D
The above parts group applies to the following Model Nos.:
ZT2148T
ZT2348T
ZT2352T
REF NO. PART NO. QTY. DESCRIPTION
Motion Control - Neutral Return Group
Footnotes:
1 22645 2 SPRING, Reverse Return
2 25155 2 WASHER, 5/16
3 25033 4 NUT, Hex, 5/16-24
4 25201-6 2 COTTER PIN
5 20979 2 CLEVIS, 5/16-24
6 25213-8 2 PIN, Clevis, 5/16 x 1
7 47137 2 REVERSE RETURN BOLT
8 25127 2 NUT, Hex, Serrated Flange, 5/16-18
9 3846918 2 BRACKET, Neutral Adjust
10 25095 2 NUT, Hex, Nylon Lock, 1/4-20
11 25011-6 2 CAPSCREW, Hex Hd, 5/16-18 x 3/4
12 25030 2 NUT, Hex, 1/4-20
13 22205 2 EYEBOLT
14 20807 2 SPRING, Extension
To Next Page
