Simplicity Colt ZT2148T

28
TP 400-7090-01-CT-D
© Copyright 2004 Ferris Industries. All Rights Reserved.
The above parts group applies to the following Model Nos.:
ZT2148T
ZT2348T
ZT2352T
Motion Control - Neutral Return Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
1
2
3
4
5
6
7
8
9
10
12
11
13
14
See Motion Control Group
NOTE: RH side shown. Unless
otherwise noted, components
are identical for the LH side.
