37
TP 400-7090-01-CT-D
The above parts group applies to the following Model Nos.:
ZT2148T (S/N: 339 & above)
ZT2348T
ZT2352T (S/N: 364 & above)
REF NO. PART NO. QTY. DESCRIPTION
Reservoir Mount & Battery Group
Footnotes:
1 22595 1 BATTERY HOLDDOWN
2 22596 2 BATTERY HOLDDOWN BOLT
3 50831-3 2 HOSE, 3”
4 * 1 BATTERY, 12V, 340 CCA Lawn & Garden
5 25144-6 4 CARRIAGE BOLT, 1/4-20 x 3/4
6 3847990 1 PLATE, Tank Mount
7 25154 4 WASHER, 1/4
8 25095 4 NUT, Hex Nylon Lock, 1/4-20
9 25127 4 NUT, Hex Serrated Flange, 5/16-18
10 25155 4 WASHER, 5/16
11 25011-8 4 CAPSCREW, Hex Head, 5/16-18 x 1
