65
TP 400-7090-04-CT-D
The above parts group applies to the following Model Nos.:
ZT2148T
ZT2348T
ZT2352T
REF NO. PART NO. QTY. DESCRIPTION
48” & 52” Mower Decks - Rear Mount Bars
Footnotes:
1 3845009 2 DECK PUSHER BAR
2 20095 2 GREASE FITTING
3 25093 2 NUT, Hex, Jam, 3/4-16
4 25265-32 2 CAPSCREW, Hex Hd, 3/4-16 x 4
5 25160 2 WASHER, 3/4
6 22111 4 ROD END SEAL
7 22039 2 BALL JOINT, 3/4-16
8 46093 2 SPACER, .75 x 1.50 x 1.00
9 25284 2 NUT, Hex, Nylon Lock, 3/4-16
10 45037 2 PUSHER BAR MOUNT PIN
11 25013-10 2 CAPSCREW, Hex Hd, 3/8-16 x 1-1/4
12 25096 2 NUT, Hex, Nylon Lock, 3/8-16
13 25156 4 WASHER, 3/8
