6
J Throttle Control
K Throttle Control SLOW Position
L Throttle Control FAST Position
M Power Take-Off (PTO)
N Power Take-Off(PTO), Engage Blades
O Power Take-Off (PTO), Disengage
Blades
P Brake Pedal
Q Ground Speed Pedals
R Mechanical Lift Lever (Broadmoor™)
S Cruise Control
T Cruise Control Lock
U Transmission Release Lever
V Fuel Level Gauge (if equipped)
W Fuel Tank
X 12 Volt Power Outlet
Y Differential Lock Pedal (if equipped)
Z Mechanical Lift Lever (Conquest™)
Electronic Dash Panel (if equipped)
4
The electronic dash panel (Figure4) shows the operation
status for a variety of equipment and engine parameters.
It gives clock and timer functions for oil and air filter
maintenance, and tracks work hours. The data is retained if
the battery is disconnected or power is interrupted.
Note:The Mower Deck Height display requires a wire
harness connection between the mower deck and the rider.
When you install the mower deck after maintenance, make
sure that the wire harness is correctly connected or the
Mower Deck Height display will not function.
