PART NO. DESCRIPTIONREF NO QTY.
Frame & Front Axle Group
Footnotes
Cap, Hub 1.51D 1 1726504SM 2
Ring, Klipring 2 1611710SM 2
Washer .828 x 1.62 x .0583 3 2860183SM 4
Axle, Front (Includes Ref. Nos. 1, 2, 3, 17 & 19) (Includes Ref. Nos. 1, 2, 3, 17 & 19) 5 1728018SM 1
Bushing, Axel Pivot 6 1730186SM 2
Hook, Hitch .312THK 7 1721918ASM 1
Capscrew HD 7/16-14 x 1.5 8 1960652SM 2
Nut, Hex-Flange 5/8-11LK 11 2860646SM 1
Nut, Hex-Flange 5/16-18LK 12 1931277SM 2
Capscrew, Hex 3/8-16 x 1.25 13 1960032SM 2
Spacer 15 1731912SM 2
Rod, Tie 16 1728080ASM 1
Spindle & Cup Assembly RH 17 1727872ASM 1
Nut, Hex-Flange 3/8-16 LK 18 1930645SM 2
Spindle & Cup Asmy LH 19 1727873ASM 1
Tower 20 1727260SM 1
Frame 21 1736499YP 1
Bolt M8 x 75 22 1735874YP 2
Nut M8 23 1735934YP 2
Washer 8.4 24 1735989YP 6
Washer 8 25 1736000YP 6
Screw, Tap 5/16-18 x 0.62 26 1930601SM 4
Bolt M8 x 20 27 1735868YP 4
Pivot, Hood 29 1728086SM 2
Support, Muffler 30 1735973YP 1
Bolt, RD HD 5/16-18 x 1.0 31 1931335SM 2
Washer 0.625 32 1960035SM 1
Capscrew, Hex 5/8-11 x 3.250 33 2860744SM 1
Link, Drag 34 1735919YP 1
Ball-Joint, CS16 M10-M12 35 1735851YP 2
Nut M12 36 1735928YP 2
Distance, Front Axle 0-9521-291 37 1735892YP 2
Nut M10 DIN6923 8 38 1735926YP 2
The above parts group applies to the following Mfg. Nos.:
5
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S
