Not for
Reproduction
PART NO. DESCRIPTIONREF NO QTY.
Engine Group
Footnotes
ENGINE, 19.5HP B&S Intek Single (Model # 441777 Type # 0128 Trim # B1) 1* 1
ENGINE, 22HP B&S Intek Twin (Model # 31P677 Type # 0116 Trim # B1) 1* 1
Valve Shut-Off 2 1717473SM 1
Shield, Heat 4 1735962YP 1
Screw, TAPTT 5/16-18 x 0.62 5 1930601SM 4
Shield, Heat (19.5HP) 6 1727996SM 1
Shield, Heat (22HP Twin) 6 1727997SM 1
Muffler B&S Twin (22HP Twin) 7 1727994SM 1
Bracket, Muffler Mount 8 1727976SM 1
Pipe, Exhaust RH Side (22HP Twin) 9 1727979SM 1
Pipe Exhaust LH Side (22HP Twin) 10 1727980SM 1
Muffler B&S Single (19.5HP) 12 1727993SM 1
Pipe, Exhaust (19.5HP) 13 1728959SM 1
Screw, TAPTT 1/4-20 x 0.5 14 1925003SM 4
Clip, Wire 15 2834683SM 1
Control, Throttle Single (19.5HP) 16 1734504SM 1
Control – Throttle Twin (22HP Twin) 16 1734505SM 1
Clamp, Hose UM5008 17 1735883YP 2
Hose, Fuel 1-9920-247 18 1735913YP 1
Clip, Hose 19 1730268SM 2
Screw, TAPTT 3/8-16 x 1.00 (19.5HP) 20 2827187SM 3
Washer, LK EXT-TOOTH .375 21 2820427SM 1
Washer, Flat .38 22 1924940SM 1
Pulley & Hub Assembly 24 1732576SM 1
Tie 25 1735980YP 1
Rod, Clutch Retainer, Long (BLK) 26 1732875SM 1
Clutch, Electric (LONG OGURA) 28 1732833SM 1
Washer, Hex .453 29 1708264SM 1
Lockwasher 7/16 30 1918199SM 1
Capscrew, Hex-Head 7/16-20 x 3.50 31 1960649SM 1
Gasket, Exhaust 32 1731214SM 1
Screw, Hex-Head T/R .38-16 x 1.25 33 2828635SM 1
Screw 34 1936228SM 2
Lockwasher 35 1917356SM 2
The above parts group applies to the following Mfg. Nos.:
9
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S
