SIMPLIHOME Harper - Page 14

Step 6
1. Attach three Cam Lock Pins 5 into pre-drilled holes on each Sides AL , AR .
2. Align Cam Lock Pins with guide holes and attach Middle Shelf N .
3. Insert six Cam Lock 5 into guide holes on Middle Shelf N .
4. Use flathead screwdriver to secure Cam Locks. Do not over-tighten.
N
5
A
L
A R
Front / Avant
Front /
Avant
Front / Avant
Front / Avant
Front /
Avant
Front / Avant
14
Model # AXCHRP-06-TKAssembly
