CLEANING AND CARING FOR YOUR OVEN (Continued)
Grill Carriage
A. Removing
The grill carriage can be fully removed to allow access for cleaning.
1. Pull grill door fully out to stops
and remove grill dish.
2. Raise the grill door to disengage stop pins.
(Make sure carriage is clear of rear pin
before lifting up).
3. Grill carriage can now be removed
from the appliance.
B. Replacing
Push slides fully into appliance, then:
1. Engage back of grill carriage over rear pins
(on both sides).
2. Lower the assembly...
3. and push grill door closed.
The grill dish can now be replaced.
Note: Ensure that the slides are pushed into
appliance when the carriage is removed.
Rear pin
Stop pin
1
3
