Simrad HS75 - Dimensional Drawings

Dimensional drawings
94.0 mm
(3.70 “)
63.5 mm
(2.50 “)
348.2 mm
(13.71 “)
9.5 mm
(0.37 “)
158.4 mm
(6.23 “)
74.45 mm
(2.93 “)
Qty. 4 - M8x1.25 - 12.7 (0.50 “)
3
12 |
Dimensional drawings | HS75 User Manual
