Introduction
Overview
The HS75 GNSS Compass supports GPS, GLONASS, Galileo, QZSS, and BeiDou satellites.
The HS75 GNSS antennas are separated by 20 cm (7.87”) between phase centers, resulting in a
heading performance of better than 0.75° RMS. The HS75 can provide heading and positioning
updates at 10 Hz and delivers positioning accuracy of 0.6 m 95% of the time when using differential
GPS corrections from Satellite Based Augmentation Systems (SBAS).
The HS75 houses the following:
Dual GNSS, multipath-resistant antennas
Six-axis rate sensor (gyro)
GNSS receivers and processors
Standard NMEA 2000 Micro-C port for power and data
The six-axis rate sensor improves system performance and provides backup heading information in
the event a GNSS heading is not available due to signal blockage. The sensor provides a substitute
heading, accurate to within 1º per minute for up to three minutes.
Parts
An HS75 installation requires the following parts:
Part name Qty.
HS75 receiver 1
NMEA 2000 drop cable (not included) 1
Fastening screws (depending on mounting option, not included) 4
Cable ties -
1
6 |
Introduction | HS75 User Manual
