Page 19
3.8 Technical Specification
Electrical
Channel Capability 54 international channels 1-28, 60-69, 71-88
Up to 10 private channels*
UK : includes M (previously 37) and M2
USA : includes 0, 29, 89, 75, 76, Wx1-10 receive only.
Scandinavia : leisure or fishing channels as appropriate.
Canada : Canadian and USA channels.
GMDSS sets have simplex channels only - 06, 08-17, 67-69, 71-74, 77
Frequency Range 155-163Mhz
Operating Temperature Range -20ºC - +60ºC
Output Power HT50 - 1 & 5 Watts Axis 50 GMDSS - 1 & 2.5 Watts
Harmonic and Spurious Emissions <.25µW Tx, <1nW Rx
Sensitivity 0.5µV for 20 dB SINAD
Selectivity 70 dB (±25 kHz)
Intermodulation 70 dB
Channel Spacing 25kHz
Blocking 90dB
Spurious Response 70dB
Audio Output Power Max 0.4 Watt
Current Consumption Squelched <25mA
Receive typically 125mA
Transmit 5 Watts 1.4A
1 Watt 0.8A
Weight 400g including battery pack
* Contact local Simrad Agent for further details of channel programming etc.
Environmental
Waterproof To a depth of 1m fully submersed, including a 45ºC thermal shock
Will withstand petrol, diesel and other fuel oils.
Drop Resistance Will withstand a drop from 1m on to a hard surface on any face.
68mm (2.7 in) 80mm (3.2 in)
145mm (5.8 in)
42mm (1.7 in)
320mm (12.8 in)
70mm (2.8 in)
96mm (3.8 in)
