Installation | V3100 User Manual
Connection to NMEA 2000 network
The V3100 is equipped with NMEA 2000 interface with LEN=1. The
device is able to send AIS data and forward received GPS data (from
NMEA 0183) via NMEA 2000 network to other NMEA 2000 devices.
For further applications e.g. heading sensor connection, please refer
to supported PGN in “NMEA 2000 PGN information” on page 30.
A compatible T-connector and drop cable, available from your local
service partner, is needed to connect the device to your chartplotter
with NMEA 2000 interface:
NMEA 2000 network
Other
NMEA2000
Device
T Connector
Backbone Cable
Drop Cable
Terminaon
Resistor
SOTDMA Class B Transponder
Chartploer
