Diagram 14
Check to ensure the remote wire harness connector is properly attached to the keyed backside of the receiver.
Diagram 15
If in thermostat mode confirm the set temperature is higher than the room temperature.
Keyed Molex Connector
Room Temperature
Set Point or Required
Temperature
Thermostat Mode
is On
46
SUREFIRE ELECTRONIC IGNITION SYSTEM
S.I.T. PROFLAME 2 TROUBLESHOOTING
