Diagram 13
Check the batteries are installed correctly in the handheld transmitter (3 x AAA) and the receiver (4 x AA)
Diagram 13a Volts DC Test (VDC)
Check the battery voltage at the X5 terminal.
While 4.4 vdc is the minimum voltage to operate it is recommended to change the batteries at 5 vdc or lower.
Receiver Batteries
Remote Handheld
Power in to IFC
45
SUREFIRE ELECTRONIC IGNITION SYSTEM
S.I.T. PROFLAME 2 TROUBLESHOOTING
SimTech Proflame II
