MAXITROL GV60 IGNITION SYSTEM
TROUBLESHOOTING
Maxitrol GV60
Diagram 14
-To test for power at the fan, set meter to AC voltage, in a range of 200VAC and place one probe on
each of the fan terminals. Reading should be 120 VAC on high. See list on page 16 for expected
voltages at other speeds.
