The remote controller includes:
- a case,
- a back-lit LCD screen displaying 4 lines of 20 characters,
- internal electronics,
- a buzzer,
- a battery unit compartment,
- a keypad with 18 keys including four function keys.
A charger is supplied with the remote controller.
Back-lit
LCD screen
4 lignes X
20 characters
case
4 function
keys
Central matrix
of 12 keys
Screen back-light
Control button
and ON/OFF
