Simu CENTRIS - Page 7

Passage of cables (all Centris range)
4
46
16
400
=
=
25°
3
4
3 4
Ø11 mm
1
2
0°
115°
25°
0°
0°
115°
0°
0°
25°
0°
1 2
Ø11 mm
2
3
4
4
5
5
1
2
5
24 N.m ±2
6 mm
3
30 N.m ±3
8 mm
3.3 - Tube preparation for motors with clamping jaws xing
3.4 - Installation of motors with clamping jaws xing (steps 1 to 5)

&

: Power supply and
declutching cables.

&

: Motor xation
3/4
r
r
r = 150 mm min.
Installation advice :
- Remove any burr and sharp edges from the tube to avoid damage to cables.
- Exit the disengagement cable in the motor alignment.
- The cables should not obstruct the rolling up of the curtain.
- Allow sufcient curvature radii (150 mm minimum) in order to prevent any blockage.
- Declutching handle assembly: See instructions sheet delivered with the declutching handle kit.
- Minimun length of the declutching cable sheath in case of shortening:
*
4,5 m /
**
Unrestricted
