Simu T3.5 DC EHz - Page 5

Ø min.
(mm)
A
(mm)
ØB
(mm)
C
(mm)
D
(mm)
L1
(mm)
L2
(mm)
A
ØB ØB
A
C
D
L2
L1
29
Ø38,2
T3.5 DC EHz
12 VDC
3Nm - 6Nm - 10Nm 37 433 4,2 8 5,5 457 470
- Drilling of the tube:
- Assembly :
1/4
1
2
40
3
4
PLASTITE FXS N7\7X12 ZING
1,2
Compatible transmitters
2
1 : Hz wall transmitter
2 : 1 / 5 channels Hz transmitters
3 : Hz timer
4 : Hz “long range” transmitter
Transmitters range :
- 1, 2 and 3 : 20 m through 2 concrete walls .
- 4 : 40 m through 2 concrete walls.
- Do not position the transmitter near metal
surface or
structure in order to avoid range losses.
Location of the “PROG” key on Hz transmitters:
PROG
PROG
412
3
S.A.S. au capital de 5 000 000 € - Z.I. Les Giranaux - BP71 - 70103 Arc-Les-Gray CEDEX - RCS GRAY B 425 650 090 - SIRET 425 650 090 00011 - n° T.V.A CEE FR 87 425 650 090
!
- Recommendations :
- Keep a minimum distance of 0.2 m
between two T3.5 DC EHz motors.
- Keep a minimum distance of 0.3 m
between T3.5 DC EHz motors and Hz transmitters.
- A radio appliance using the same frequency (433,42 MHz) may deteriorate our product’s performance (ex. :
hi-fi radio headphones).
Installation
1
Read carefully these
instructions before any use.
GB T3.5 DC EHz
5055191B
Hereby, SIMU, declares that this equipment “T3.5 DC EHz” is in compliance with the essential requirements and other
relevant provision of Directive 1999/5/EC. A declaration of Conformity is available at the web address: www.simu.fr,
heading “Normes”. Usable in UE,
1 32 4
