◆ Description of Air Conditioner Components
Indoor Unit
Outdoor Unit
(1) Front Panel
(2) Guide louver
(3) Receiving window
(5) Wall Pipe
(6) Wrapping Tape
(7) Drainage hose
(8) Connection pipe
Air inlet
Air Outlet
- - 6
⑸
⑴
⑶
⑵
⑷
Air inlet
Air Outlet
（７）
（６）
and connection wire
Wireless remote control
Heat (This indicator
is black for single-
Cooling
cooling unit).
Set Temp
（８）
(4) LED Board
