9
display the next address is 15.
Press this button for minus temperature
at wire temperature setting mode.
Press this button for minus clock or time
at wire clock or time setting mode.
12 13 PAGEUP/DOWN button to spot
check the operation parameters of unit in
the main menu.
14 HYSTERESIS button (Hidden)
Use a small round bar with 1mm
diameter to press this button, then can
adjust the return parameter δ＝(2,3,4,5
℃). The numerical valve of hystersis can
be adjusted by “ADDRESS/+” and
“ADDRESS/-”, after the adjustment then
press the OK button for the setting
confirmation.
The factory defaults δ＝2℃.
15 LOCK button (Hidden)
Use a 1mm-diameter round bar to lock
the current setting. Press this button
again to unlock.
16 ADDRESS SET button (Hidden)
The address of wire controller can be set
by pressing this button. The address
range 0~15, therefore, 16 wire controller
could be parallel at most.
When there is only one wire controller, it
is necessary to execute this setting, the
address of wire controller should be set
to '0'(main wire controller) .
17 TIMER QUERY button
Press the button can inquire the timer
setting information,such as the week,the
setting operation mode,the start
period,the end period and the setting
temperature and so on.
18 TIMER SWITCH button
Press the button can open the weekly
timer function or close the weekly timer
function.
