Sinclair SCV-50EA - Electric Characteristics

8. Electric Characteristics
Model
Outdoor Unit Power Supply Compressor OFM
Hz Voltage Phase Min. Max. MCA TOCA MFA MSC RLA kW FLA
SCV-50EA 50Hz 220~240V 1Ph 198V
264V 10.1 14.6 20 29.5 8.1 0.195 1.65
SCV-70EA 50Hz 220~240V 1Ph 198V
264V 10.1 15.6 20 29.5 8.1 0.195 1.65
SCV-100EA 50Hz 220~240V 1Ph
198V 264V 15.1 25.0 30 52 12.1 0.20 1.8
SCV-120EA 50Hz 380~415V 3Ph
342V 456V 8.6 8.9 15 44 6.9 0.20 1.8
SCV-140EA 50Hz 380~415V 3Ph
342V 456V 8.6 9.6 15 44 6.9 0.20 1.8
SCV-160EA 50Hz 380~415V 3Ph
342V 456V 8.6 10.1 15 44 6.9 0.20 1.8
Remark:
MCA: Min. Current Amps. (A)
TOCA: Total Over-current Amps. (A)
MFA: Max. Fuse Amps. (A)
MSC: Max. Starting Amps. (A)
RLA: Rated Current Amps. (A)
OFM: Outdoor Fan Motor
FLA: Full Load Amps. (A)
kW: Rated Motor Output (kW)
17
