Table 7.2: High Static Pressure Duct heating capacity (continued)
Capacity
(kW)
Outdoor air
temperature (°C )
Indoor air temperature (°C DB)
16
18
20
21
22
24
TC
TC
TC
TC
TC
TC
WB
DB
kW
kW
kW
kW
kW
kW
14.0
-20
-19.8
8.96
8.96
8.96
8.96
8.96
8.96
-19
-18.8
9.60
9.60
9.60
9.60
9.60
9.60
-17
-16.7
10.08
10.08
10.08
10.08
10.08
10.08
-15
-14.7
10.40
10.40
10.40
10.40
10.40
10.40
-13.00
-12.60
11.04
11.04
11.04
11.04
11.04
11.04
-11.00
-10.50
11.20
11.36
11.36
11.36
11.36
11.36
-10.00
-9.50
11.68
11.68
11.68
11.68
11.68
11.68
-9.10
-8.50
12.00
12.00
12.00
12.00
12.00
12.00
-7.60
-7.00
12.16
12.16
12.16
12.16
12.16
12.16
-5.60
-5.00
12.64
12.64
12.64
12.64
12.64
12.64
-3.70
-3.00
13.28
13.28
13.28
13.28
13.28
13.28
-0.70
0.00
14.24 14.24
14.24
14.24
14.24
13.44
2.20
3.00
15.04 15.04
15.04
15.04
14.72
13.44
4.10
5.00
15.52 15.52
15.52
15.52
14.72
13.44
6.00
7.00
16.00 16.00
16.00
15.52
14.72
13.44
7.90
9.00
16.48 16.48
16.00
15.52
14.72
13.44
9.80
11.00
16.96 16.96
16.00
15.52
14.72
13.44
11.80
13.00
17.60 17.28
16.00
15.52
14.72
13.44
13.70
15.00
18.08 17.28
16.00
15.52
14.72
13.44
16.0
-20
-19.8
9.52 9.52
9.52
9.52
9.52
9.52
-19
-18.8
10.20 10.20
10.20
10.20
10.20
10.20
-17
-16.7
10.71 10.71
10.71
10.71
10.71
10.71
-15
-14.7
11.05
11.05
11.05
11.05
11.05
11.05
-13.00
-12.60
11.73
11.73
11.73
11.73
11.73
11.73
-11.00
-10.50
11.90
12.07
12.07
12.07
12.07
12.07
-10.00
-9.50
12.41
12.41
12.41
12.41
12.41
12.41
-9.10
-8.50
12.75
12.75
12.75
12.75
12.75
12.75
-7.60
-7.00
12.92
12.92
12.92
12.92
12.92
12.92
-5.60
-5.00
13.43
13.43
13.43
13.43
13.43
13.43
-3.70
-3.00
14.11
14.11
14.11
14.11
14.11
14.11
-0.70
0.00
15.13
15.13
15.13
15.13
15.13
14.28
2.20
3.00
15.98
15.98
15.98
15.98
15.64
14.28
4.10
5.00
16.49
16.49
16.49
16.49
15.64
14.28
6.00
7.00
17.00
17.00
17.00
16.49
15.64
14.28
7.90
9.00
17.51
17.51
17.00
16.49
15.64
14.28
9.80
11.00
18.02
18.02
17.00
16.49
15.64
14.28
11.80
13.00
18.70
18.36
17.00
16.49
15.64
14.28
13.70
15.00
19.21
18.36
17.00
16.49
15.64
14.28
Abbreviations:
TC: Total capacity
Notes:
1. Shaded cells indicate rating condition.
Table continued on next page …
