Sinclair SDV5 Series Service Manual

4 201806
1 Specifications
SDV5-71DHA / SDV5-80DHA / SDV5-90DHA
Table 1.1: SDV5-71,80,90DHA specifications
Model name
SDV5-71DHA SDV5-80DHA SDV5-90DHA
Power supply
1-phase, 220-240V, 50Hz
Cooling
1
Capacity
kW
7.1
8
9
kBut/h
24.2
27.3
30.7
Input
W
180
180
220
Heating
2
Capacity
kW
8
9
10
kBut/h
27.3
30.7
34.1
Input
W
180
180
220
Fan motor
Model
WZDK750-38G-W
WZDK750-38G-W
WZDK750-38G-W
Type
DC
Brand
Panasonic/ Welling
Speed (H/M/L)
r/min 970/950/940/910/880/860/840 980/950/930/900/870/840/810
Coil
Number of rows
2
2
3
Tube pitch × row
pitch
mm 25.4×22
25.4×22
25.4×22
Fin spacing
mm 1.5
1.5
1.6
Fin type
Hydrophilic aluminum
Tube OD and type
mm Ф9.53 Inner groove
Dimensions (L×H
×W)
mm 700×356×44
700×356×44
700×356×66
Number of circuits
3
3
7
Airflow rate
3
m
3
/h
1360/1327/1293/1260/1227/1193/1160
1420/1373/1327/1280/
1233/1187/1140
External static pressure
4
Pa
100 (30~ 200)
Sound pressure level
5
dB(A)
46/46/45/45/44/43/42
46/46/45/45/44/43/42
50/49/48/48/47/46/45
Unit
Net dimensions
6
(W×H×D)
mm
965.5×423.5×690
Packed dimensions
(W×H×D)
mm
1090×440×768
Net/Gross weight
kg
41/47
41/47
51/57
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Model
BD20FKS(L)
Design pressure (H/L)
MPa
4.4/2.6
Pipe
connections
Liquid/Gas pipe
mm
Ф9.53/Ф15.9
Drain pipe
mm
OD Ф25
Notes:
1. Indoor temperature 27°C DB, 19°C WB; outdoor temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.
2. Indoor temperature 20°C DB; outdoor temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.
3. Fan motor speed and air flow rate are from the highest speed to the lowest speed, total 7 rates for each model.
4. Stable operation external static pressure range. (Note: setting external static pressure outside the unit’s optimal static pressure range may lead to
higher noise levels and lower airflow rate. For the optimal external static pressure range refer to the unit’s installation manual.)
5. Sound pressure level is from highest level to lowest level, total 7 levels for each model. Sound pressure level is measured 1.4m below the unit in a
semi-anechoic chamber.
6. Unit body dimensions given are the largest external dimensions of the unit, including hanger attachments.
