Sinclair SDV5 Series Service Manual

18 201806
7 Capacity Tables
7.1 Cooling Capacity Table
Table 7.1: High Static Pressure Duct cooling capacity
Capacity
(kW)
Outdoor air
temperature
(°C DB)
Indoor air temperature (°C WB/DB)
14/20
16/23
18/26
19/27
20/28
22/30
24/32
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
7.1
10.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
9.2
5.6
12.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
9.1
5.5
14.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
9.0
5.5
16.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
8.9
5.4
18.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
8.7
5.2
20.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
8.5
5.2
21.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
8.4
5.1
23.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.3
5.6
8.3 5.0
25.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.2
5.5
8.2 5.0
27.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.2
5.5
8.2 5.0
29.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.1
5.4
8.1 5.0
31.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.0
5.4
7.8 4.8
33.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.0
5.3
7.8 4.8
35.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.3
7.7
5.1
7.7 4.8
37.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.4
5.3
7.7
5.1
7.6 4.8
39.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.2
5.2
7.4
5.0
7.6 4.8
42.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.2
5.2
7.4
5.0
7.6 4.8
44.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.2
5.2
7.4
5.0
7.6 4.8
46.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.2
5.2
7.4
5.0
7.6 4.8
8.0
10.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
10.4
6.3
12.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
10.2
6.2
14.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
10.2
6.1
16.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
10.0
6.0
18.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
9.8
5.9
20.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
9.6
5.8
21.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
9.4
5.7
23.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.4
6.3
9.4
5.7
25.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.3
6.2
9.3
5.6
27.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.2
6.2
9.2
5.7
29.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.1
6.1
9.1
5.6
31.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.0
6.1
8.8
5.4
33.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.0
6.0
8.8
5.4
35.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.4
6.0
8.6
5.8
8.6
5.4
37.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.3
5.9
8.6
5.8
8.6
5.4
39.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.2
5.8
8.3
5.7
8.6
5.5
42.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.2
5.8
8.3
5.7
8.6
5.5
44.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.2
5.8
8.3
5.7
8.6
5.5
46.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.2
5.8
8.3
5.7
8.6
5.5
Abbreviations:
TC: Total capacity
SC: Sensible capacity
Notes:
1. Shaded cells indicate rating condition.
Table continued on next page …
