No Description Part Code Note Qty Price Code

1 E-Part box cover 12226000000009 1

2 E-part box assembly 17226000002659 1

2.1 Reactance 17400306000163 1

2.2 Radiator Components 17127000006656 1

2.2.1

Module board assembly 17127000006679 1

2.2.2 Radiator 11203803002876 1

2.2.3 rectifier bridge 11201418000014 1

2.3 Indoor unit main control board 17126000003317 1

2.4 Wire joint 17400401001516 1

2.5 Wire joint 17400401000156 1

2.6 Clip 12222200001925 1

2.7 Insulation plate 12122000006931 1

3 Side board ass’y 12226000003496 1

4 Front panel assembly 12223000000145 1

5 Centrifugal fan 12200102000023 1

6 Motor 11002015000348 1

7 Bearin supporting board 12226000000369 1

8 Fan motor ass'y 12226000000012 1

9 Top cover assembly 12226000000794 1

10 Centrifugal fan 12200102000006 1

11 Left clapboard ass'y 12223000001065 1

12 Pipe temperature sensor assemblies 11201007000030 1

13 Pipe temperature sensor 11201007000025 1

14 chassis ass'y 12226000003453 1

15 beam ass'y 12226000000440 1

16 Drain tray 12822500000131 1

17 Supporting board ass'y, evaporator 12226000000811 1

18 Evaporator ass'y 15826000000040 1

19 air fresh filter 12100204A00159 1

20 Rear clapboard 12223000000160 1

21 Evaporator right support board subassembly 12223000000292 1

22 cover plate 12226000000292 1

23 Fixing board, pipes 12223000001708 1

Pipe fixing clamp 12223000001610 1

MODEL: SDV5-140DHA HIGH STATIC PRESSURE DUCT UNIT
