No Description Part Code Note Qty Price Code
1 E-Part box cover 12226000000009 1
2 E-part box assembly 17226000002659 1
2.1 Reactance 17400306000163 1
2.1 Reactance 17400306000163 1
2.2
Radiator Components 17127000006656 1
2.2 Radiator Components 17127000006656 1
2.2.1 Module board assembly 17127000006679 1
2.2.1 Module board assembly 17127000006679 1
2.2.2 Radiator 11203803002876 1
2.2.2 Radiator 11203803002876 1
2.2.3 rectifier bridge 11201418000014 1
2.2.3 rectifier bridge 11201418000014 1
2.3 Indoor unit main control board 17126000003317 1
2.3 Indoor unit main control board 17126000003317 1
2.4 Wire joint 17400401001516 1
2.4 Wire joint 17400401001516 1
2.5 Wire joint 17400401000156 1
2.5 Wire joint 17400401000156 1
2.6 Clip 12222200001925 1
2.6 Clip 12222200001925 1
2.7 Insulation plate 12122000006931 1
2.7 Insulation plate 12122000006931 1
3 Side board ass’y 12226000003496 1
4 Front panel assembly 12223000000145 1
5 Centrifugal fan 12200102000023 1
6 Motor 11002015000348 1
7 Bearin supporting board 12226000000369 1
8 Fan motor ass'y 12226000000012 1
9 Top cover assembly 12226000000794 1
10
Centrifugal fan 12200102000006
1
11
Left clapboard ass'y 12223000001065
1
12
Pipe temperature sensor assemblies 11201007000030
1
13
Pipe temperature sensor 11201007000025
1
14
chassis ass'y 12226000003453
1
15
beam ass'y 12226000000440
1
16
Drain tray 12822500000131
1
17
Supporting board ass'y, evaporator 12226000000811
1
18
Evaporator ass'y 15826000000040
1
19
air fresh filter 12100204A00159
1
20
Rear clapboard 12223000000160
1
21
Evaporator right support board subassembly 12223000000292
1
22
cover plate 12226000000292
1
23
Fixing board, pipes 12223000001708
1
24
Pipe fixing clamp 12223000001610
1
MODEL: SDV5-160DHA HIGH STATIC PRESSURE DUCT UNIT
