No Description Part Code Note Qty Price Code
1 Electric control box cover assembly 12223000010829 1
2 E-part box assembly 17226000002663 1
2.1 Indoor unit main control board 17126000003320 1
2.2 Radiator assembly 17127000006663 1
2.2.1
rectifier bridge 11201418000014 2
2.2.2 Module board assembly 17127000006676 1
2.3 Reactance 17400306000785 1
2.4 Capacitor 17400103000146 1
2.5 reactor 17400306000307 1
3 Side board ass’y 12226000003473 1
4 connecting board ass'y 12226000000224 1
5 Centrifugal fan 12200102000012 1
6 Chassis assembly 12223000010834 1
7 Below flange ass'y 12226000000301 1
8 Motor support 12226000003614 1
9 Fan-motor assembly 12226000003474 1
10 Flange assembly 12226000000004 1
11 Left clapboard ass'y 12226000000283 1
12 Volute shell ass'y 12200101000019 1
13 Brushless DC Motor 11002015007704 1
14 Beam ass'y 12226000000791 1
15 Top cover ass'y 12226000000792 1
16 Connecting board ass'y 12226000000231 1
17 Below flange ass'y 12226000000301 1
18 Fixing board ass'y, drain tray 12226000000249 1
19 Left clapboard ass'y 12226000000270 1
20 Drainage tray ass'y 12226000000243 1
21 Evaporator ass 15826000002132 1
22 Flange ass'y 12226000000005 1
23 Top cover ass'y 12226000000212 1
24 Air filter 12100204001739 1
25 Pipe clamp board assembly 12226000002154 1
26
Fixing board, pipes 12223000001708 1
27
Pipe fixing clamp 12223000001610 1
28
Pipe clamp board assembly 12226000002156 1
29 Side panel ass'y 12226000003497 1
MODEL: SDV5-280DHA HIGH STATIC PRESSURE DUCT UNIT
