Sinclair SDV5 Series Service Manual

6 201806
SDV5-200DHA / SDV5-250DHA / SDV5-280DHA
Table 1.3: SDV5-200,250,280DHA specifications
Model name
SDV5-200DHA SDV5-250DHA SDV5-280DHA
Power supply
1-phase, 220-240V, 50Hz
Cooling
1
Capacity
kW
20
25
28
kBut/h
68.2
85.3
95.5
Input
W
990
990
1200
Heating
2
Capacity
kW
22.5
26
31.5
kBut/h
76.8
88.7
107.5
Input
W
990
990
1200
Fan motor
Model
ZKSN-920-8-12
ZKSN-920-8-12
ZKSN-920-8-12
Type
DC
Brand
Nidec/Yongan
Speed (H/M/L)
r/min
1210/1180/1150/1130/1100/1080/1050
Coil
Number of rows
4
4
4
Tube pitch × row pitch
mm 25.4×22
25.4×22
25.4×22
Fin spacing
mm 1.8
1.8
1.8
Fin type
Hydrophilic aluminum
Tube OD and type
mm Ф9.53 Inner groove
Dimensions (L×H ×W)
mm 1125×512×88
1125×512×88
1125×512×88
Number of circuits
20
20
20
Airflow rate
3
m
3
/h 4330/4230/4130/4030/3930/3830/3730
External static pressure
4
Pa 170 (20~250)
Sound pressure level
5
dB(A) 57/56/55/54/53/52/50
Unit
Net dimensions
6
(W×H×D)
mm
1454×515×931
Packed dimensions
(W×H×D)
mm
1509×550×990
Net/Gross weight
kg
130/142
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Model
D20MISZ-1R(L)
Design pressure (H/L)
MPa
4.4/2.6
Pipe
connections
Liquid/Gas pipe
mm
Ф12.7/Ф22.2
Drain pipe
mm
OD Ф32
Notes:
1. Indoor temperature 27°C DB, 19°C WB; outdoor temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.
2. Indoor temperature 20°C DB; outdoor temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.
3. Fan motor speed and air flow rate are from the highest speed to the lowest speed, total 7 rates for each model.
4. Stable operation external static pressure range. (Note: setting external static pressure outside the unit’s optimal static pressure range may lead to
higher noise levels and lower airflow rate. For the optimal external static pressure range refer to the unit’s installation manual.)
5. Sound pressure level is from highest level to lowest level, total 7 levels for each model. Sound pressure level is measured 1.4m below the unit in a
semi-anechoic chamber.
6. Unit body dimensions given are the largest external dimensions of the unit, including hanger attachments.
