Sinclair SDV5 Series User Manual

3
2. PART NAMES
■ Four-way cassette type
Air Outlet Louver (adjustable)
Lock buckle
(for closing the Air Grille)
Air Intake
Air Filter
Grounding Screw
(in the control box)
for in-situ adjustment to three-direction or two-direction,
please contact the local dealer .
■ Ceiling-floor type(36-71kW)
Horizontal Air Outlet Louver
Air Intake
Air Filter(inside)
■ One-way cassette type(18-36kW)
Fig.2-1
Fig.2-2
Air Intake
Air Filter
Grille Bolt-lock
Air Outlet Louver
Display Panel
Fig.2-5
Fig.2-3
■ Ceiling-floor type(80-90kW)
The figure shown above is for reference only and may
be slightly diffferent from the actual product.
Horizontal Air Outlet Louver
Air Filter(inside)
Air Intake
Fig.2-4
■ Ceiling-floor type(112-140kW)
Horizontal Air Outlet Louver
Air Filter(inside)
Air Intake
